GVW                                                Driving Type 4x2

Model

CLW

Cab

Tianjin a row and a half deluxe cab(with sleeping berth),hydraulic mechanical flip, channel type instrument panel, air conditioner, allowable 3 passengers

Engine(Hp)

190

Power(Kw)

140

Wheelbase

4700

Front/Rear Suspension

1430/2860

Steering

Power steering

Approach/departure angle

20/10

Wheels & tire

10.00-20

Tire number

6+1

Working height(m)

22

RHD or LHD

optional

Overall Dimensions(mm)

10100×2500×3800

Curb weight (Kg)

10825

Engine

Model

B190 33

Horsepower

190

Maximum output Kw

140

Maximum torque N.m

640

Type

6cylinders, in-line,4-stroke,water-cooled,turbo inter-cooling, diesel engine

Displacement

5900ml

Cummins, Euro 3

Driving passenger

2,3

Transmission

8 speed forward and one reverse, manual

Front Axle

5T

Rear Axle

10T

Brake System

air brake

exhaust brake

Color and LOGO

customized

Electric system

24V

Standard configuration

Double operation systems, bucket insulation,3 booms, hydraulic oil tank, 500kg lifting hook, box truck body design,4 hydraulic H-shape legs,2 signal lamps,2 tool boxes.

Equipment

Platform Dimension

1100X570X1000mm

Max Working Height

22m

Max Working Radius

8m

Angle Of Rotation

360°

Platform Loading

200kg

Platform Passenger

2

Rotating Speed

0-2m

Delivery date

Within 30 days after receipt advance

Packing

Nude Pack .The packing of the commodity shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture, shocks and rust according to the special needs of the commodity.
