GVW                                                 Driving Type 4x2

Model

CLW

Cab

Double row cab, allowable 2+3 passengers.

Engine(Hp)

82

Power(Kw)

60

Wheelbase

3300

Front/Rear Suspension

1032/1968

Steering

Power steering

Approach/departure angle

19/11

Wheels & tire

7.00R16

Tire number

6+1

Working height(m)

12

RHD or LHD

optional

Overall Dimensions(mm)

7400×2000×3100

Curb weight (Kg)

5000

Engine

Model

CY4100Q

Horsepower

82

Maximum output Kw

60

Maximum torque N.m

Type

4cylinders, in-line,4-stroke,diesel engine

Displacement

3.7L

Chaoyang brand, Euro 2

Driving passenger

2+3

Transmission

5 speed forward and one reverse, manual

Front Axle

2T

Rear Axle

4T

Brake System

air brake

exhaust brake

Color and LOGO

customized

Electric system

24V

Standard configuration

Double operation systems, bucket insulation,3 booms, hydraulic oil tank, 500kg lifting hook, box truck body design,4 hydraulic H-shape legs,2 signal lamps,2 tool boxes.

Equipment

Platform Dimension

1080X620X1100 mm

Max Working Height

12m

Max Working Radius

straight

Angle Of Rotation

360

Platform Loading

200kg

Platform Passenger

2

Rotating Speed

0-2m

Delivery date

Within 30 days after receipt advance

Packing

Nude Pack .The packing of the commodity shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture, shocks and rust according to the special needs of the commodity.
