GVW                                                  Driving Type 4x2

Model

CLW

Cab

Tianlong D310 a row and a half deluxe cab(with sleeping berth),hydraulic mechanical flip, channel type instrument panel, power window,air conditioner, allowable 3 passengers

Engine(Hp)

290

Power(Kw)

213

Wheelbase

4350+1300

Front/Rear Suspension

1460/2340

Steering

Power steering

Approach/departure angle

20/12

Wheels & tire

11.00R20

Tire number

10+1

Tank capacity(m3)

18

RHD or LHD

optional

Overall Dimensions(mm)

9600×2500×3550

Curb weight (Kg)

12500

Engine

Model

WP10.290E32

Horsepower

290

Maximum output Kw

213

Maximum torque N.m

1160

Type

6 cylinders, in-line,4-stroke,diesel engine

Displacement

9.726L

Weichai engine brand, Euro 3

Driving passenger

2,3

Transmission

10 speed forward and one reverse, manual

Front Axle

5T

Rear Axle

10Tx2

Brake System

air brake

exhaust brake

Color and LOGO

customized

Electric system

24V

Standard configuration

Vacuum pump, ball valve, oil cylinder for rear cap, oil cylinder for dumping, pressure meter, window for showing liquid level, lock system for rear cap, four-way valve, moisture separator, etc.

Optional configuration

Watering system, liquid full alarm device

Delivery date

Within 30 days after receipt advance

Packing

Nude Pack .The packing of the commodity shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture, shocks and rust according to the special needs of the commodity.
