GVW                                                   Driving Type 4x2

Model

CLW

Cab

Dongfeng a row and a half cab(with sleeping berth), allowable 3 passengers

Engine(Hp)

210

Power(Kw)

155

Wheelbase

4350+1350

Front/Rear Suspension

1250/2250

Steering

Power steering

Approach/departure angle

20/15

Wheels & tire

10.00-20

Tire number

10+1

Tank capacity(m3)

16

RHD or LHD

optional

Overall Dimensions(mm)

9600×2500×3400

Curb weight (Kg)

11800

Engine

Model

B210 33

Horsepower

210

Maximum output Kw

155

Maximum torque N.m

700

Type

6 cylinders, in-line,4-stroke,diesel engine

Displacement

5.9L

Cummins engine brand, Euro 3

Driving passenger

2,3

Transmission

8 speed forward and one reverse, manual

Front Axle

5T

Rear Axle

10Tx2

Brake System

air brake

exhaust brake

Color and LOGO

customized

Electric system

24V

Standard configuration

Vacuum pump, ball valve, oil cylinder for rear cap, oil cylinder for dumping, pressure meter, window for showing liquid level, lock system for rear cap, four-way valve, moisture separator, etc.

Optional configuration

Watering system, liquid full alarm device

Delivery date

Within 30 days after receipt advance

Packing

Nude Pack .The packing of the commodity shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture, shocks and rust according to the special needs of the commodity.
