GVW                                                   Driving Type 4x2

Model

CLW

Cab

Tianjin a row and a half deluxe cab(with sleeping berth),hydraulic mechanical flip, channel type instrument panel, power window,air conditioner, allowable 3 passengers

Engine(Hp)

190

Power(Kw)

140

Wheelbase

4500

Front/Rear Suspension

1430/2820

Steering

Power steering

Approach/departure angle

20/13

Wheels & tire

10.00-20

Tire number

6+1

Tank capacity(m3)

10

RHD or LHD

optional

Overall Dimensions(mm)

8800×2500×2900

Curb weight (Kg)

8025

Engine

Model

B190 33

Horsepower

190

Maximum output Kw

140

Maximum torque N.m

640

Type

6 cylinders, in-line,4-stroke,diesel engine

Displacement

5.9L

Cummins engine brand, Euro 3

Driving passenger

2,3

Transmission

8 speed forward and one reverse, manual

Front Axle

5T

Rear Axle

10T

Brake System

air brake

exhaust brake

Color and LOGO

customized

Electric system

24V

Standard configuration

carbon steel fecal tank,6 meters fecal suction pipe, rotating arm, domestic vacuum pump, oil and gas separator, water vapor separator, anti overflow valve, observation tube, gravity flow valve

Optional configuration

Watering system, liquid full alarm device

Delivery date

Within 30 days after receipt advance

Packing

Nude Pack .The packing of the commodity shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture, shocks and rust according to the special needs of the commodity.
