GVW                                                   Driving Type 4x2

Model

CLW

Cab

One row cab, tilted

Engine(Hp)

140

Power(Kw)

103

Wheelbase

3800

Front/Rear Suspension

1180/1820

Steering

Power steering

Approach/departure angle

22/12

Wheels & tire

7.50R16

Tire number

6+1

Tank capacity(m3)

6

RHD or LHD

optional

Overall Dimensions(mm)

6800×2300×2650

Curb weight (Kg)

4705

Engine

Model

B140 33

Horsepower

140

Maximum output Kw

103

Maximum torque N.m

Type

4 cylinders, in-line,4-stroke,diesel engine

Displacement

3.9L

Cummins engine brand, Euro 3

Driving passenger

2,3

Transmission

6 speed forward and one reverse, manual

Front Axle

2.5T

Rear Axle

4.5T

Brake System

air brake

exhaust brake

Color and LOGO

customized

Electric system

24V

Standard configuration

carbon steel fecal tank,6 meters fecal suction pipe, rotating arm, domestic vacuum pump, oil and gas separator, water vapor separator, anti overflow valve, observation tube, gravity flow valve

Optional configuration

Watering system, liquid full alarm device

Delivery date

Within 20 days after receipt advance

Packing

Nude Pack .The packing of the commodity shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture, shocks and rust according to the special needs of the commodity.
