GVW                                                 Driving Type 4x2

Model

CLW

Cab

Sharp head cab

Engine(Hp)

170

Power(Kw)

125

Wheelbase

3950

Front/Rear Suspension

1065/1975

Steering

Power steering

Approach/departure angle

34/22

Wheels & tire

9.0R20

Tire number

6+1

Tank capacity(m3)

6

RHD or LHD

optional

Overall Dimensions(mm)

7000×2400×3100

Curb weight (Kg)

5800

Engine

Model

B170 33

Horsepower

170

Maximum output Kw

125

Maximum torque N.m

560

Type

6 cylinders, in-line,4-stroke,turbo,diesel engine

Displacement

5.9L

Cummins engine brand, Euro 3

Driving passenger

2,3

Transmission

8 speed forward and one reverse, manual

Front Axle

3.6T

Rear Axle

9T

Brake System

air brake

Color and LOGO

customized

Electric system

24V

Standard configuration

Vacuum pump, ball valve, oil cylinder for rear cap, oil cylinder for dumping, pressure meter, window for showing liquid level, lock system for rear cap, four-way valve, moisture separator, etc.

Optional configuration

Watering system, liquid full alarm device

Delivery date

Within 30 days after receipt advance

Packing

Nude Pack .The packing of the commodity shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture, shocks and rust according to the special needs of the commodity.
