GVW                                                   Driving Type 4x2

Model

CLW

Cab

One row cab,electric window,central lock, tilted

Engine(Hp)

102

Power(Kw)

75

Wheelbase

2800

Front/Rear Suspension

1180/1520

Steering

Power steering

Approach/departure angle

20/18

Wheels & tire

185R15

Tire number

6+1

Body Dimensions(mm)

3100×1500×500

Cubage (m3)

2.5

Steel thickness

Side 3 ,Bottom 4

RHD or LHD

LHD

Overall Dimensions(mm)

5500×1900×2080

Curb weight (Kg)

2200

Engine

Model

JE393ZLQ3A

Horsepower

102

Maximum output Kw

75

Maximum torque N.m

240

Type

4 cylinders, in-line,4-stroke,diesel engine

Displacement

2.771L

JMC brand, Euro 2

Driving passenger

2

Transmission

5 speed forward and one reverse, manual

Front Axle

1.5T

Rear Axle

3T

Brake System

Oil brake

Color and LOGO

customized

Electric system

12V

Standard configuration

The dump is unloaded from behind, hydraulic cover is optional. The side protection using cold-formed steel /Q235-A, bolt connection. The back protection using cold-formed steel /Q235-A, welding connection. Side 3mm, bottom 4mm.

Delivery date

Within 30 days after receipt advance

Packing

Nude Pack .The packing of the commodity shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture, shocks and rust according to the special needs of the commodity.
