GVW                                                    Driving Type 4x2

Model

CLW

Cab

Isuzu 700P single row cab, tilted,air con

Engine(Hp)

190

Power(Kw)

141

Wheelbase

3815

Front/Rear Suspension

1110/1775

Steering

Power steering

Approach/departure angle

21/15

Wheels & tire

235/75R17.5

Tire number

6+1

Tank capacity(m3)

7

RHD or LHD

LHD

Overall Dimensions(mm)

6700×2200×2950

Curb weight (Kg)

6200

Engine

Model

4HK1-TC51

Horsepower

190

Maximum output Kw

141

Maximum torque N.m

510

Type

4 cylinders, in-line,4-stroke,diesel engine

Displacement

5193L

Isuzu brand, Euro 5

Driving passenger

3

Transmission

Isuzu MLD 6 speed forward and one reverse, manual

Front Axle

4T

Rear Axle

7T

Brake System

air brake

Color and LOGO

customized

Electric system

24V

Standard configuration

Vacuum pump, ball valve, oil cylinder for rear cap, oil cylinder for dumping, pressure meter, window for showing liquid level, lock system for rear cap, four-way valve, moisture separator, etc.

Optional configuration

Watering system, liquid full alarm device

Delivery date

Within 40 days after receipt advance

Packing

Nude Pack .The packing of the commodity shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture, shocks and rust according to the special needs of the commodity.
