GVW                                                    Driving Type 4x2

Model

CLW

Cab

Isuzu 600P single row cab, tilted,air con

Engine(Hp)

130

Power(Kw)

96

Wheelbase

3360

Front/Rear Suspension

1015/1435

Steering

Power steering

Approach/departure angle

24/20

Wheels & tire

7.00R16

Tire number

6+1

Tank capacity(m3)

4/5

RHD or LHD

LHD

Overall Dimensions(mm)

5900×1900×2570

Curb weight (Kg)

4000

Engine

Model

4KH1CN5HS

Horsepower

130

Maximum output Kw

96

Maximum torque N.m

290

Type

4 cylinders, in-line,4-stroke,diesel engine

Displacement

2.999L

Isuzu brand, Euro 5

Driving passenger

2

Transmission

Isuzu MSB 5 speed forward and one reverse, manual

Front Axle

2T

Rear Axle

4.8T

Brake System

oil brake

Color and LOGO

customized

Electric system

24V

Standard configuration

Vacuum pump, ball valve, oil cylinder for rear cap, oil cylinder for dumping, pressure meter, window for showing liquid level, lock system for rear cap, four-way valve, moisture separator, etc.

Optional configuration

Watering system, liquid full alarm device

Delivery date

Within 40 days after receipt advance

Packing

Nude Pack .The packing of the commodity shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture, shocks and rust according to the special needs of the commodity.
