GVW                                                Driving Type 4x2

Model

CLW

Cab

One and a half cab with a sleeper, tilted

Engine(Hp)

190

Power(Kw)

140

Wheelbase

4500

Front/Rear Suspension

1230/2870

Steering

Power steering

Approach/departure angle

19/10

Wheels & tire

10.00R20

Tire number

6+1

Tank Dimensions(mm)

/

Cubage (m3)

10

Steel thickness of tank(mm)

4

RHD or LHD

LHD

Overall Dimensions(mm)

8600×2500×3200

Curb weight (Kg)

7105

Engine

Model

B190 33

Horsepower

190

Maximum output Kw

140

Maximum torque N.m

640

Type

6 cylinders, in-line, inter-cooling,TURBO,diesel engine

Displacement

5.900L

Cummins brand, Euro 3

Driving passenger

2,3

Transmission

8 speed forward and one reverse, manual

Front Axle

5T

Rear Axle

10T

Brake System

air brake

exhaust brake

Color and LOGO

customized

Electric system

24V

Tank material

Carbon steel, stainless steel, aluminum, etc. alloy, etc.

Sprinkling width

14m each side

Suction height

7m

Standard configuration

carbon steel water tank, manhole, water pump, front/side/rear spray nozzle, rear working platform, water cannon, fire valve, water valve, filter gauze, water hose, climbing ladder.

Optional configuration

Stainless steel/aluminum alloy water tank, insulation layer for water tank, stainless steel water pump, fire pump, fire gun, pesticide plate, cabin gas control operated, Honda pumps, lights, crane, hanging basket, rear spraying device, barrel pesticide spraying device, gasoline pesticide machine, diesel pesticide machine, LED arrow lights

Delivery date

Within 30 days after receipt advance

Packing

Nude Pack .The packing of the commodity shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture, shocks and rust according to the special needs of the commodity.
