GVW                                                    Driving Type 4x2

Model

CLW

Cab

Howo light duty cab ,one row cab, tilted

Engine(Hp)

116

Power(Kw)

85

Wheelbase

3360

Front/Rear Suspension

1160/1390

Steering

Power steering

Approach/departure angle

27/16.5

Wheels & tire

7.0R16

Tire number

6+1

Body Dimensions(mm)

3600×1800×500

Payload (T)

3-4

Steel thickness

Side 3 ,Bottom 4

RHD or LHD

LHD

Overall Dimensions(mm)

5995×2000×2300

Curb weight (Kg)

3300

Engine

Model

YN4102QBZL

Horsepower

116

Maximum output Kw

85

Maximum torque N.m

290

Type

4 cylinders, in-line,4-stroke, diesel engine

Displacement

3.76L

Yunnei brand, Euro 2

Driving passenger

2

Transmission

WLY 6 speed forward and one reverse, manual

Front Axle

2.4T

Rear Axle

4.2T

Brake System

air brake

Color and LOGO

customized

Electric system

24V

Standard configuration

The dump is unloaded from behind, hydraulic cover is optional. The side protection using cold-formed steel /Q235-A, bolt connection. The back protection using cold-formed steel /Q235-A, welding connection. Side 3mm, bottom 4mm.

Delivery date

Within 60 days after receipt advance

Packing

Nude Pack .The packing of the commodity shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture, shocks and rust according to the special needs of the commodity.
