GVW                                   Driving Type 4x2

Model

CLW

Cab

One row and half cab, tilted

Engine(Hp)

129

Power(Kw)

95

Wheelbase

3250

Front/Rear Suspension

1530/1600

Steering

Power steering

Approach/departure angle

22/17

Wheels & tire

8.25R16

Tire number

6+1

Tank Dimensions(mm)

3650×2000×600,800

Cubage (m3)

4/5

Steel thickness

Side 3 ,Bottom 4

RHD or LHD

optional

Overall Dimensions(mm)

5900×2200×2600

Curb weight (Kg)

2720

Engine

Model

YN38CRE1

Horsepower

129

Maximum output Kw

95

Maximum torque N.m

Type

4 cylinders, in-line, turbo inter-cooling, diesel engine

Displacement

3.76L

Yuchai brand, Euro 5

Driving passenger

2

Transmission

5 speed forward and one reverse, manual

Front Axle

2.8T

Rear Axle

5T

Brake System

air brake

exhaust brake

Color and LOGO

customized

Electric system

24V

Standard configuration

The dump is unloaded from behind, hydraulic cover is optional. The side protection using cold-formed steel /Q235-A, bolt connection. The back protection using cold-formed steel /Q235-A, welding connection. Side 3mm, bottom 4mm.

Delivery date

Within 20 days after receipt advance

Packing

Nude Pack .The packing of the commodity shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture, shocks and rust according to the special needs of the commodity.
