GVW                                                  Driving Type 4x2

Model

CLW

Cab

ISUZU FVR cab, tilted,air con

Engine(Hp)

240

Power(Kw)

177

Wheelbase

3900

Front/Rear Suspension

1335/1900

Steering

Power steering

Approach/departure angle

28/20

Wheels & tire

295/80R22.5

Tire number

6+1

Tank Dimensions(mm)

5200,5400×2300×800,1000

Cubage (m3)

10-12

Steel thickness

Side 4 ,Bottom 4

RHD or LHD

LHD

Overall Dimensions(mm)

7800,8000×2500×3100

Curb weight (Kg)

7200

Engine

Model

6HK1-TCL

Horsepower

240

Maximum output Kw

177

Maximum torque N.m

/

Type

6 cylinders, in-line,4-stroke , diesel engine

Displacement

7.79L

ISUZU brand, Euro 5

Driving passenger

3

Transmission

ISUZU MLD 6 speed forward and one reverse, manual

Front Axle

6.3T

Rear Axle

13T

Brake System

air brake

Color and LOGO

customized

Electric system

24V

Standard configuration

The dump is unloaded from behind, hydraulic cover is optional. The side protection using cold-formed steel /Q235-A, bolt connection. The back protection using cold-formed steel /Q235-A, welding connection. Side 4mm, bottom 4mm.

Delivery date

Within 40 days after receipt advance

Packing

Nude Pack .The packing of the commodity shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture, shocks and rust according to the special needs of the commodity.
