GVW                                                 Driving Type 6x4

Model

CLW

Cab

Dongfeng KC standard flat roof a row and a half deluxe cab(with sleeping berth)cab, air conditioner, electric glass, hydraulic mechanical flip, channel type instrument panel, allowable 3 passengers

Engine(Hp)

340

Power(Kw)

250

Wheelbase

3800+1350

Front/Rear Suspension

1500/1650

Steering

Power steering

Approach/departure angle

25/17

Wheels & tire

12.00R20

Tire number

10+1

Tank Dimensions(mm)

5600×2300×1500

Cubage (m3)

18

Steel thickness

Side 6 ,Bottom 8

RHD or LHD

optional

Overall Dimensions(mm)

8300×2500×3450

Curb weight (Kg)

11900

Engine

Model

L340 30

Horsepower

340

Maximum output Kw

250

Maximum torque N.m

1350

Type

6 cylinders, in-line,4-stroke, diesel engine

Displacement

8.9L

Cummins brand, Euro 3

Driving passenger

2,3

Transmission

FAST 12 speed , manual

Front Axle

7.5T

Rear Axle

13Tx2

Brake System

air brake

exhaust brake

Color and LOGO

customized

Electric system

24V

Standard configuration

The dump is unloaded from behind, hydraulic cover is optional. The side protection using cold-formed steel /Q235-A, bolt connection. The back protection using cold-formed steel /Q235-A, welding connection. Side 6mm, bottom 8mm,middle lift

Delivery date

Within 30 days after receipt advance

Packing

Nude Pack .The packing of the commodity shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture, shocks and rust according to the special needs of the commodity.
