GVW                                                   Driving Type 6x4

Model

CLW

Cab

A row and a half cab(with sleeping berth),allowable 3 passengers

Engine(Hp)

260

Power(Kw)

191

Wheelbase

3800+1300

Front/Rear Suspension

1250/1650

Steering

Power steering

Approach/departure angle

32/35

Wheels & tire

11.00R20

Tire number

10+1

Tank Dimensions(mm)

5600×2300×1200

Cubage (m3)

15/20

Steel thickness

Side 6 ,Bottom 8

RHD or LHD

optional

Overall Dimensions(mm)

8100×2500×3450

Curb weight (Kg)

12000

Engine

Model

YC6A260-33

Horsepower

260

Maximum output Kw

191

Maximum torque N.m

960

Type

6 cylinders, in-line,4-stroke, diesel engine

Displacement

7.255L

Yuchai brand, Euro 3

Driving passenger

2,3

Transmission

FAST 9 speed forward and one reverse, manual

Front Axle

5T

Rear Axle

10Tx2

Brake System

air brake

exhaust brake

Color and LOGO

customized

Electric system

24V

Standard configuration

The dump is unloaded from behind, hydraulic cover is optional. The side protection using cold-formed steel /Q235-A, bolt connection. The back protection using cold-formed steel /Q235-A, welding connection. Side 6mm, bottom 8mm.

Delivery date

Within 30 days after receipt advance

Packing

Nude Pack .The packing of the commodity shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture, shocks and rust according to the special needs of the commodity.
