GVW                                                 Driving Type 4x2

Model

CLW

Cab

Tianjin KR a row and a half deluxe cab(with sleeping berth),hydraulic mechanical flip, channel type instrument panel, air conditioner, allowable 3 passengers

Engine(Hp)

210

Power(Kw)

155

Wheelbase

4500

Front/Rear Suspension

1430/1850

Steering

Power steering

Approach/departure angle

25/20

Wheels & tire

10.00R20

Tire number

6+1

Tank Dimensions(mm)

5400×2300×800,1000

Cubage (m3)

10-12

Steel thickness

Side 4 ,Bottom 5

RHD or LHD

optional

Overall Dimensions(mm)

8000×2500×3200

Curb weight (Kg)

7000

Engine

Model

B210 33

Horsepower

210

Maximum output Kw

155

Maximum torque N.m

700

Type

6 cylinders, in-line,4-stroke,water-cooled,turbo inter-cooling, diesel engine

Displacement

5.9L

Cummins brand, Euro 3

Driving passenger

3

Transmission

FAST 8 speed forward and one reverse, manual

Front Axle

5T

Rear Axle

10T

Brake System

air brake

exhaust brake

Color and LOGO

customized

Electric system

24V

Standard configuration

The dump is unloaded from behind, hydraulic cover is optional. The side protection using cold-formed steel /Q235-A, bolt connection. The back protection using cold-formed steel /Q235-A, welding connection. Side 4mm, bottom 5mm.

Delivery date

Within 30 days after receipt advance

Packing

Nude Pack .The packing of the commodity shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture, shocks and rust according to the special needs of the commodity.
