GVW                                                   Driving Type 4x2

Model

CLW

Cab

One row cab, tilted

Engine(Hp)

129

Power(Kw)

95

Wheelbase

3800

Front/Rear Suspension

1180/1250

Steering

Power steering

Approach/departure angle

21/15

Wheels & tire

7.5R16

Tire number

6+1

Tank Dimensions(mm)

4150×2000×600,800

Cubage (m3)

Steel thickness

Side 3 ,Bottom 4

RHD or LHD

optional

Overall Dimensions(mm)

6300×2300×2600

Curb weight (Kg)

5000

Engine

Model

YCD4F32-129

Horsepower

129

Maximum output Kw

95

Maximum torque N.m

/

Type

4 cylinders, in-line,4-stroke,water-cooled,turbo inter-cooling, diesel engine

Displacement

3.922L

Yuchai brand, Euro 3

Driving passenger

2,3

Transmission

5 speed forward and one reverse, manual

Front Axle

2.5T

Rear Axle

4.5T

Brake System

air brake

exhaust brake

Color and LOGO

customized

Electric system

24V

Standard configuration

The dump is unloaded from behind, hydraulic cover is optional. The side protection using cold-formed steel /Q235-A, bolt connection. The back protection using cold-formed steel /Q235-A, welding connection. Side 3mm, bottom 4mm.

Delivery date

Within 20 days after receipt advance

Packing

Nude Pack .The packing of the commodity shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture, shocks and rust according to the special needs of the commodity.
