GVW                                                  Driving Type 6x4

Model

CLW

Cab

D310 standard flat roof a row and a half deluxe cab(with sleeping berth),air conditioner, electric glass, hydraulic mechanical flip, channel type instrument panel, central lock, allowable 3 passengers

Engine(Hp)

260

Power(Kw)

191

Wheelbase

5350+1350

Front/Rear Suspension

1480/2320

Steering

Power steering

Approach/departure angle

18/12

Wheels & tire

10.00R20

Tire number

10+1

Tank Dimensions(mm)

Cubage (m3)

Water tank 12 ,dust tank 10

RHD or LHD

optional

Overall Dimensions(mm)

10700×2500×3400

Curb weight (Kg)

17500

Engine

Model

C260 33

Horsepower

260

Maximum output Kw

191

Maximum torque N.m

1090

Type

6 cylinders, in-line,4-stroke ,turbo inter-cooling, diesel engine

Displacement

8.300L

Cummins brand, Euro 3

Driving passenger

2,3

Transmission

9 speed forward and one reverse, manual

Front Axle

5T

Rear Axle

10T X2

Brake System

air brake ,exhaust brake

Color and LOGO

customized

Electric system

24V

Sweeper and washing

Water tank

12m3

Dust tank

10m3

Sweeping width

3.5m

Cleaning efficiency

98%

Unloading angle

45°

Maximum suction particle

120mm

Max cleaning ability

70000 m2/h

Sweeping speed

3-25km/h

Standard configuration

2 sweeping brushes,vacuum tank, water tank with anti-overflow or low water level alarm , German high pressure water pump ,front and rear road flushing system ,garbage tank self cleaning system. auxiliary engine, Siemens control switch, American sensor,hydraulic system and electrical system ,reversing and cleaning state indoor monitor led arrow lamb and 18m high pressure cleaning reel and so on .

Delivery date

Within 30 days after receipt advance

Packing

Nude Pack .The packing of the commodity shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture, shocks and rust according to the special needs of the commodity.
