GVW                                           Driving Type 4x2

Model

CLW

Cab

Howo light duty cab ,one and half row cab, tilted

Engine(Hp)

116

Power(Kw)

85

Wheelbase

3360

Front/Rear Suspension

1160/1405

Steering

Power steering

Approach/departure angle

20/23

Wheels & tire

7.0R16

Tire number

6+1

Tank Dimensions(mm)

3400×1600×1100

Cubage (m3)

5

Steel thickness of tank(mm)

4

RHD or LHD

optional

Overall Dimensions(mm)

6000×2000×2450

Curb weight (Kg)

3165

Engine

Model

YN4102QBZL

Horsepower

116

Maximum output Kw

85

Maximum torque N.m

290

Type

4 cylinders, in-line,4-stroke,water-cooled,turbo inter-cooling, diesel engine

Displacement

3.76L

Yunnei brand, Euro 2

Driving passenger

2

Transmission

WLY 6 speed forward and one reverse, manual

Front Axle

2.4T

Rear Axle

4.2T

Brake System

air brake

Color and LOGO

customized

Electric system

24V

Tank material

Carbon steel

Sprinkling width

14m each side

Suction height

7m

Standard configuration

carbon steel water tank, manhole, water pump, front/side/rear spray nozzle, rear working platform, water cannon, fire valve, water valve, filter gauze, water hose, climbing ladder.

Delivery date

Within 60 days after receipt advance

Packing

Nude Pack .The packing of the commodity shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture, shocks and rust according to the special needs of the commodity.
