GVW                                                 Driving Type 4x2

Model

CLW

Cab

Isuzu 600P one row cab, tilted

Engine(Hp)

130

Power(Kw)

96

Wheelbase

3360

Front/Rear Suspension

1015/1825

Steering

Power steering

Approach/departure angle

24/13

Wheels & tire

7.0R16

Tire number

6+1

Tank Dimensions(mm)

Cubage (m3)

Water tank 1 ,dust tank 4

RHD or LHD

LHD

Overall Dimensions(mm)

6200×2000×2600

Curb weight (Kg)

4900

Engine

Model

4KH1CN5HS

Horsepower

130

Maximum output Kw

96

Maximum torque N.m

290

Type

4 cylinders, in-line, 4-stroke,diesel engine

Displacement

2.999L

ISUZU brand, Euro 5

Driving passenger

2,3

Transmission

ISUZU MSB 5 speed forward and one reverse, manual

Front Axle

2.5T

Rear Axle

4.8T

Brake System

oil brake

Color and LOGO

customized

Electric system

24V

Sweeper

Water tank

1m3

Dust tank

4m3

Sweeping width

2.5m

Cleaning efficiency

98%

Unloading angle

45°

Maximum suction particle

70mm

Max cleaning ability

70000 m2/h

Sweeping speed

3-25km/h

Standard configuration

vacuum tank, water tank with lift and dump function, fan, auxiliary engine, electromagnetic control valve, suction cup, high-precision trash filter system , hydraulic system and electrical system and rear spray humidifying function so on.

Delivery date

Within 50 days after receipt advance

Packing

Nude Pack .The packing of the commodity shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture, shocks and rust according to the special needs of the commodity.
