GVW                                                   Driving Type 4x2

Model

CLW

Cab

One row cab, tilted

Engine(Hp)

82

Power(Kw)

60

Wheelbase

3300

Front/Rear Suspension

1032/1638

Steering

Power steering

Approach/departure angle

19/12

Wheels & tire

7.0R16

Tire number

6+1

Tank Dimensions(mm)

/

Cubage (m3)

Water tank 1.5 ,dust tank 4

RHD or LHD

optional

Overall Dimensions(mm)

6000×2000×2400

Curb weight (Kg)

4900

Engine

Model

CY4100Q

Horsepower

82

Maximum output Kw

60

Maximum torque N.m

/

Type

4 cylinders, in-line,4-stroke,diesel engine

Displacement

3.7L

Chaoyang brand, Euro 2

Driving passenger

2,3

Transmission

5 speed forward and one reverse, manual

Front Axle

2T

Rear Axle

4T

Brake System

air brake  ,exhaust brake

Color and LOGO

customized

Electric system

24V

Sweeper

Water tank

1.5m3

Dust tank

4m3

Sweeping width

3m

Cleaning efficiency

98%

Unloading angle

45°

Maximum suction particle

120mm

Max cleaning ability

70000 m2/h

Sweeping speed

3-25km/h

Standard configuration

Tank body,4 sweeping brushes, stainless steel vacuum tank, water tank,5T fan, auxiliary engine, electromagnetic control valve, suction cup, hydraulic system and electrical system and so on.

Optional configuration

Front and rear road flushing system , garbage tank self cleaning system.

Delivery date

Within 30 days after receipt advance

Packing

Nude Pack .The packing of the commodity shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture, shocks and rust according to the special needs of the commodity.
