GVW                                                  Driving Type 4x2

Model

CLW

Cab

Tianjin a row and a half deluxe cab(with sleeping berth),hydraulic mechanical flip, channel type instrument panel, power window,air conditioner, allowable 3 passengers

Engine(Hp)

190

Power(Kw)

140

Wheelbase

4500

Front/Rear Suspension

1430/2500

Steering

Power steering

Approach/departure angle

20/15

Wheels & tire

10.00R20

Tire number

6+1

Tank Dimensions(mm)

Cubage (m3)

12

Steel thickness of tank(mm)

4

RHD or LHD

optional

Overall Dimensions(mm)

8430×2480×2850

Curb weight (Kg)

7305

Engine

Model

B190 33

Horsepower

190

Maximum output Kw

140

Maximum torque N.m

640

Type

6cylinders, in-line,4-stroke,water-cooled,turbo inter-cooling, diesel engine

Displacement

5900ml

Cummins, Euro 3

Driving passenger

3

Transmission

FAST 8 speed forward and one reverse, manual

Front Axle

5T

Rear Axle

10T

Brake System

air brake

exhaust brake

Color and LOGO

Customized

Electric system

24V

Tank material

carbon steel

Sprinkling width

14m each side

Suction height

7m

Standard configuration

carbon steel water tank, manhole, water pump, front/side/rear spray nozzle, rear working platform, water cannon, fire valve, water valve, filter gauze, water hose, climbing ladder.

Delivery date

Within 20 days after receipt advance

Packing

Nude Pack .The packing of the commodity shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture, shocks and rust according to the special needs of the commodity.
