GVW                                                  Driving Type 4x2

Model

CLW

Cab

A row and a half cab(with sleeping berth),allowable 3 passengers

Engine(Hp)

170

Power(Kw)

125

Wheelbase

3950

Front/Rear Suspension

1250/1200

Steering

Power steering

Approach/departure angle

34/22

Wheels & tire

9.0-20

Tire number

6+1

Garbage bin capacity(m3)

10

RHD or LHD

optional

Overall Dimensions(mm)

6400×2500×2750

Curb weight (Kg)

5800

Engine

Model

B170 33

Horsepower

170

Maximum output Kw

125

Maximum torque N.m

560

Type

6 cylinders, in-line,4-stroke,water-cooled,turbo inter-cooling, diesel engine

Displacement

5.900L

Cummins brand, Euro 3

Driving passenger

2,3

Transmission

8 speed forward and one reverse, manual

Front Axle

3.6T

Rear Axle

9T

Brake System

air brake

exhaust brake

Color and LOGO

customized

Electric system

24V

Standard configuration

Hook lift system , sub frame, lock cylinder, multiple valve, operating handle, one garbage container.

Delivery date

Within 20 days after receipt advance

Packing

Nude Pack .The packing of the commodity shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture, shocks and rust according to the special needs of the commodity.
