GVW                                                 Driving Type 4x2

Model

CLW

Cab

ISUZU 600P cab, tilted,air con

Engine(Hp)

130

Power(Kw)

96

Wheelbase

3360

Front/Rear Suspension

1015/925

Steering

Power steering

Approach/departure angle

24/15

Wheels & tire

7.0 R16

Tire number

6+1

Garbage bin capacity(m3)

5

RHD or LHD

LHD

Overall Dimensions(mm)

5300×2000×2300

Curb weight (Kg)

2800

Engine

Model

4KH1CN5HS

Horsepower

130

Maximum output Kw

96

Maximum torque N.m

290

Type

4 cylinders, in-line,4-stroke ,turbo inter-cooling, high pressure common rail, DOC ,diesel engine

Displacement

2999ml

ISUZU brand, Euro 5

Driving passenger

2

Transmission

ISUZU MSB 5 speed forward and one reverse, manual

Front Axle

2-2.5T

Rear Axle

4.8T

Brake System

oil brake

exhaust brake

Color and LOGO

customized

Electric system

24V

Standard configuration

Telescope hook lift system , sub frame, lock cylinder, multiple valve, operating handle,rear hydraulic legs, remote control operation from cabin, electric control,and etc

Delivery date

Within 40 days after receipt advance

Packing

Nude Pack .The packing of the commodity shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture, shocks and rust according to the special needs of the commodity.
