GVW                                                    Driving Type 6x4

Model

CLW

Cab

FAW one and a half cab(with sleeping berth),allowable 3 passengers,air con

Engine(Hp)

290

Power(Kw)

213

Wheelbase

3700+1350

Front/Rear Suspension

1375/2900

Steering

Power steering

Approach/departure angle

28/10

Wheels & tire

315/80R22.5

Tire number

10+1

Tank Dimensions(mm)

/

Cubage (m3)

18

Steel thickness of tank(mm)

5

RHD or LHD

optional

Overall Dimensions(mm)

9800×2500×3200

Curb weight (Kg)

9900

Engine

Model

WP10.290E32

Horsepower

290

Maximum output Kw

213

Maximum torque N.m

1160

Type

6 cylinders, in-line,4-stroke,water-cooled,turbo inter-cooling, diesel engine

Displacement

9.726L

Weichai brand, Euro 3

Driving passenger

3

Transmission

FAST 9 speed forward and one reverse, manual

Front Axle

7.5T

Rear Axle

16T with double

Brake System

air brake

exhaust brake

Color and LOGO

customized

Electric system

24V

Tank material

Carbon steel

Sprinkling width

14m each side

Suction height

7m

Standard configuration

carbon steel water tank, manhole, water pump, front/side/rear spray nozzle, rear working platform, water cannon, fire valve, water valve, filter gauze, water hose, climbing ladder.

Delivery date

Within 50 days after receipt advance

Packing

Nude Pack .The packing of the commodity shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture, shocks and rust according to the special needs of the commodity.
