GVW14000kg                                          Driving Type 4x2

Model

CLW

Cab

One and half row cab, tilted

Engine(Hp)

140

Power(Kw)

105

Wheelbase

4500

Front/Rear Suspension

1160/1700

Steering

Power steering

Approach/departure angle

18/23

Wheels & tire

8.25R20

Tire number

6+1

Garbage bin capacity(m3)

10

RHD or LHD

optional

Overall Dimensions(mm)

7300×2500×2900

Curb weight (Kg)

6500

Engine

Model

YC4E140-33

Horsepower

140

Maximum output Kw

105

Maximum torque N.m

500

Type

4 cylinders, in-line,4-stroke,turbo,diesel engine

Displacement

4.257L

Yuchai brand, Euro 3

Driving passenger

2,3

Transmission

6 speed forward and one reverse, manual

Front Axle

3.2T

Rear Axle

8T

Brake System

air brake

Color and LOGO

customized

Electric system

24V

Standard configuration

Bin lift system , garbage box with rear door, with dump function.

Optional configuration

Hydraulic open rear door,garbage compression function

Delivery date

Within 60 days after receipt advance

Packing

Nude Pack .The packing of the commodity shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture, shocks and rust according to the special needs of the commodity.
