GVW                                                  Driving Type 4x2

Model

CLW

Cab

Single cab, tilted

Engine(Hp)

120

Power(Kw)

88

Wheelbase

3800

Front/Rear Suspension

1180/1200

Steering

Power steering

Approach/departure angle

20/19

Wheels & tire

7.5R16 ,8.25 -16

Tire number

6+1

Garbage bin capacity(m3)

7

RHD or LHD

optional

Overall Dimensions(mm)

6200×2200×2500

Curb weight (Kg)

4405

Engine

Model

CY4102BZQ

Horsepower

120

Maximum output Kw

88

Maximum torque N.m

324

Type

4 cylinders, in-line,4-stroke,water-cooled,turbo inter-cooling, diesel engine

Displacement

3,856L

Chaoyang brand, Euro 2

Driving passenger

2,3

Transmission

5 speed forward and one reverse, manual

Front Axle

2.5T

Rear Axle

4.5T

Brake System

air brake

exhaust brake

Color and LOGO

customized

Electric system

24V

Standard configuration

Bin lift system , garbage box with rear door, with dump function.

Optional configuration

Hydraulic open rear door,garbage compression function

Delivery date

Within 30 days after receipt advance

Packing

Nude Pack .The packing of the commodity shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture, shocks and rust according to the special needs of the commodity.
