GVW                                                   Driving Type 4x2

Model

CLW

Cab

Single cab, tilted

Engine(Hp)

95

Power(Kw)

70

Wheelbase

2800

Front/Rear Suspension

1190/1060

Steering

Power steering

Approach/departure angle

20/14

Wheels & tire

6.0R15

Tire number

6+1

Garbage bin capacity(m3)

3

RHD or LHD

LHD

Overall Dimensions(mm)

5100×2000×2300

Curb weight (Kg)

3000

Engine

Model

Q23-95E60

Horsepower

95

Maximum output Kw

70

Maximum torque N.m

Type

4 cylinders, in-line,4-stroke,diesel engine

Displacement

2.3L

Quanchai brand, Euro 6

Driving passenger

2

Transmission

5 speed forward and one reverse, manual

Front Axle

1.5T

Rear Axle

3T

Brake System

oil brake

Color and LOGO

customized

Electric system

24V

Standard configuration

Bin lift system , garbage box with rear door, with dump function.

Optional configuration

Hydraulic open rear door,garbage compression function

Delivery date

Within 20 days after receipt advance

Packing

Nude Pack .The packing of the commodity shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture, shocks and rust according to the special needs of the commodity.
