GVW                                                   Driving Type 4x2

Model

CLW

Cab

Single cab, tilted

Engine(Hp)

112

Power(Kw)

82

Wheelbase

2750

Front/Rear Suspension

1075/1115

Steering

Power steering

Approach/departure angle

22/18

Wheels & tire

175R14

Tire number

6+1

Garbage bin capacity(m3)

3

RHD or LHD

LHD

Overall Dimensions(mm)

5000×2000×2200

Curb weight (Kg)

2300

Engine

Model

DAM15L

Horsepower

112

Maximum output Kw

82

Maximum torque N.m

Type

4 cylinders, in-line,4-stroke,petrol engine

Displacement

1.498L

DongAn brand, Euro 5

Driving passenger

2

Transmission

5 speed forward and one reverse, manual

Front Axle

1.2T

Rear Axle

2T

Brake System

oil brake

Color and LOGO

customized

Electric system

24V

Standard configuration

Bin lift system , garbage box with rear door, with dump function.

Optional configuration

Hydraulic open rear door,garbage compression function

Delivery date

Within 40 days after receipt advance

Packing

Nude Pack .The packing of the commodity shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture, shocks and rust according to the special needs of the commodity.
