GVW                                                Driving Type 4x2

Model

CLW

Cab

Isuzu 700P single row cab, tilted,air con

Engine(Hp)

192

Power(Kw)

141

Wheelbase

3815

Front/Rear Suspension

1110/2000

Steering

Power steering

Approach/departure angle

20/8

Wheels & tire

235/75R17.5

Tire number

6+1

Compactor capacity(m3)

7-8

RHD or LHD

LHD

Overall Dimensions(mm)

7200×2200×2650

Curb weight (Kg)

6350

Engine

Model

4HK1-TC51

Horsepower

192

Maximum output Kw

141

Maximum torque N.m

510

Type

4 cylinders, in-line, 4-stroke,diesel engine

Displacement

5193ml

ISUZU brand, Euro 5

Driving passenger

3

Transmission

ISUZU MLD 6 speed forward and one reverse, manual

Front Axle

4T

Rear Axle

7T

Brake System

air brake

Color and LOGO

customized

Electric system

24V

Standard configuration

Compactor body, sub frame, rear lifting part, loading bunker, pushing-out plate, hydraulic system, pressing system, sewage tank, climbing ladder, pneumatic control ,PLC control.

Selective equipment

Rear side arm swing type turning over instrument

compactor

capacity

7-8m3

Loading cycle

15-30s

Unloading cycle

20-30s

Compressed proportion

1:3/1:2

Garbage bin turning over instrument

available

Different instrument selective

Delivery date

Within 40 days after receipt advance

Packing

Nude Pack .The packing of the commodity shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture, shocks and rust according to the special needs of the commodity.
