GVW                                                  Driving Type 4x2

Model

CLW

Cab

SINOTRUK HW76 Lengthen cab, single bunk, new type seat, adjustable steering wheel ,EURO new type heating & ventilating system, German VDO instruments, safety belts, exterior sun visor, stereo radio/cassette recorder, air conditioner

Engine(Hp)

266

Power(Kw)

196

Wheelbase

4600

Front/Rear Suspension

1500/2170

Steering

Power steering

Approach/departure angle

22/15

Wheels & tire

295/80R22.5

Tire number

6+1

Garbage bin capacity(m3)

10

RHD or LHD

optional

Overall Dimensions(mm)

8000×2500×3500

Curb weight (Kg)

8000

Engine

Model

WD615.62

Horsepower

266

Maximum output Kw

196

Maximum torque N.m

1100

Type

6 cylinders, in-line,4-stroke,water-cooled,turbo inter-cooling, diesel engine

Displacement

9.726L

Sinotruk brand, Euro 2

Driving passenger

2,3

Transmission

HW13710 , 10 forwards,2 reverse

Front Axle

HF 7

Rear Axle

ST 16

Color and LOGO

customized

Electric system

24V

Standard configuration

two balancing valves, two domestic oil cylinders, rear hydraulic legs, unloading container locking pins

Delivery date

Within 40 days after receipt advance

Packing

Nude Pack .The packing of the commodity shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture, shocks and rust according to the special needs of the commodity.
