GVW                                                   Driving Type 4x2

Model

CLW

Cab

Sino H5 type a row and a half deluxe cab(with sleeping berth), allowable 3 passengers

Engine(Hp)

190

Power(Kw)

140

Wheelbase

4200

Front/Rear Suspension

1250/2150

Steering

Power steering

Approach/departure angle

16/17

Wheels & tire

9.0R20

Tire number

6+1

Garbage bin capacity(m3)

10

RHD or LHD

optional

Overall Dimensions(mm)

7600×2500×3400

Curb weight (Kg)

9200

Engine

Model

YC6J190-33

Horsepower

190

Maximum output Kw

140

Maximum torque N.m

630

Type

6 cylinders, in-line,4-stroke,water-cooled, diesel engine

Displacement

6.5L

Yuchai brand, Euro 3

Driving passenger

3

Transmission

6 speed forward and one reverse, manual

Front Axle

4.3T

Rear Axle

10T

Brake System

air brake

exhaust brake

Color and LOGO

customized

Electric system

24V

Standard configuration

two balancing valves, two domestic oil cylinders, one garbage container, rear hydraulic legs, unloading container locking pins

Optional configuration

Garbage container cover,remote control ,electric control

Delivery date

Within 60 days after receipt advance

Packing

Nude Pack .The packing of the commodity shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture, shocks and rust according to the special needs of the commodity.
