GVW                                                  Driving Type 4x2

Model

CLW

Cab

Single cab, tilted

Engine(Hp)

120

Power(Kw)

88

Wheelbase

3800

Front/Rear Suspension

1130/1870

Steering

Power steering

Approach/departure angle

21/10

Wheels & tire

7.5 R16

Tire number

6+1

Garbage bin capacity(m3)

6

RHD or LHD

optional

Overall Dimensions(mm)

6800×2300×2900

Curb weight (Kg)

4800

Engine

Model

CY4102BZQ

Horsepower

120

Maximum output Kw

88

Maximum torque N.m

Type

4 cylinders, in-line,4-stroke, diesel engine

Displacement

3,86L

Chaoyang brand, Euro 2

Driving passenger

2,3

Transmission

5 speed forward and one reverse, manual

Front Axle

2.5T

Rear Axle

4.5T

Brake System

air brake

exhaust brake

Color and LOGO

customized

Electric system

24V

Standard configuration

two balancing valves, two domestic oil cylinders, one garbage container, rear hydraulic legs, unloading container locking pins

Optional configuration

Garbage container cover

Delivery date

Within 20 days after receipt advance

Packing

Nude Pack .The packing of the commodity shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture, shocks and rust according to the special needs of the commodity.
