GVW                                                                      Driving Type 4x2

Model

CLW

Cab

SHACMAN L3000 deluxe cab,air con,power window,LED daytime running light,central lock,hydraulic major seat,tilt

Engine(Hp)

210

Power(Kw)

155

Wheelbase

4500

Front/Rear Suspension

1340/2760

Steering

Power steering

Approach/departure angle

21/12

Wheels & tire

10.00R20

Tire number

6+1

Compactor capacity(m3)

12

RHD or LHD

optional

Overall Dimensions(mm)

8600×2500×3250

Curb weight (Kg)

9900

Engine

Model

WP6.210E32

Horsepower

210

Maximum output Kw

155

Maximum torque N.m

750

Type

6cylinders, in-line,4-stroke,water-cooled, diesel engine

Displacement

6.23L

Weichai brand, Euro 3

Driving passenger

3

Transmission

Fast 8 speed forward and one reverse, manual

Front Axle

4.8T

Rear Axle

10T

Brake System

air brake

exhaust brake

Color and LOGO

customized

Electric system

24V

Standard configuration

Compactor body, sub frame, rear lifting part, loading bunker, pushing-out plate, hydraulic system, pressing system, sewage tank, climbing ladder, pneumatic control ,PLC control.

Selective equipment

Rear side arm swing type instrument

compactor

capacity

12m3

Loading cycle

15-30s

Unloading cycle

20-30s

Compressed proportion

1:3/1:2

Garbage bin turning over instrument

available

Different instrument selective

Delivery date

Within 40 days after receipt advance

Packing

Nude Pack .The packing of the commodity shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture, shocks and rust according to the special needs of the commodity.
