GVW                                                   Driving Type 4x2

Model

CLW

Cab

Isuzu 100P single row cab, tilted,air con

Engine(Hp)

98

Power(Kw)

72

Wheelbase

3360

Front/Rear Suspension

1015/2085

Steering

Power steering

Approach/departure angle

24/11

Wheels & tire

7.0R16

Tire number

6+1

Compactor capacity(m3)

5

RHD or LHD

LHD

Overall Dimensions(mm)

6850×2100×2650

Curb weight (Kg)

5150

Engine

Model

4KH1CN5LS

Horsepower

98

Maximum output Kw

72

Maximum torque N.m

220

Type

4 cylinders, in-line, 4-stroke,diesel engine

Displacement

2999ml

ISUZU brand, Euro 5

Driving passenger

2

Transmission

ISUZU MSB 5 speed forward and one reverse, manual

Front Axle

2T

Rear Axle

4T

Brake System

Double circuit oil brake

Color and LOGO

customized

Electric system

12V

Standard configuration

Compactor body, sub frame, rear lifting part, loading bunker, pushing-out plate, hydraulic system, pressing system, sewage tank, climbing ladder, pneumatic control ,PLC control.

Selective equipment

Rear side arm swing type turning over instrument

compactor

capacity

5m3

Loading cycle

15-30s

Unloading cycle

20-30s

Compressed proportion

1:3/1:2

Garbage bin turning over instrument

available

Different instrument selective

Delivery date

Within 40 days after receipt advance

Packing

Nude Pack .The packing of the commodity shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture, shocks and rust according to the special needs of the commodity.
