GVW                                                    Driving Type 6x4

Model

CLW

Cab

SINOTRUK HW76 Lengthen cab, single bunk, new type seat, adjustable steering wheel ,EURO new type heating & ventilating system, German VDO instruments, safety belts, exterior sun visor, stereo radio/cassette recorder, air conditioner

Engine(Hp)

400

Power(Kw)

280

Wheelbase

4325+1350,4600+1350

Front/Rear Suspension

1500/2870

Steering

Power steering

Approach/departure angle

16/15

Wheels & tire

315/80R22.5

Tire number

10+1

Compactor capacity(m3)

18

RHD or LHD

optional

Overall Dimensions(mm)

10400×2500×3500

Curb weight (Kg)

16200

Engine

Model

WP10.400E201

Horsepower

400

Maximum output Kw

280

Maximum torque N.m

1500

Type

6cylinders, in-line,4-stroke,water-cooled,turbo inter-cooling, diesel engine

Displacement

11596ml

Weichai brand, Euro 2

Driving passenger

2

Transmission

HW19710,10 forwards,2 reverse

Front Axle

HF7

Rear Axle

ST16x2

Brake System

air brake

exhaust brake

Color and LOGO

customized

Electric system

24V

Standard configuration

Compactor body, sub frame, rear lifting part, loading bunker, pushing-out plate, hydraulic system, pressing system, sewage tank, climbing ladder, pneumatic control ,PLC control.

Selective equipment

Rear side arm swing type turning over instrument

compactor

capacity

18m3

Loading cycle

15-30s

Unloading cycle

20-30s

Compressed proportion

1:3/1:2

Garbage bin turning over instrument

available

Different instrument selective

Delivery date

Within 40 days after receipt advance

Packing

Nude Pack .The packing of the commodity shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture, shocks and rust according to the special needs of the commodity.
