GVW                                                  Driving Type 8x4

Model

CLW

Cab

One and a half cab with a sleeper, tilted

Engine(Hp)

260

Power(Kw)

191

Wheelbase

1950+4200+1350

Front/Rear Suspension

1250/3200

Steering

Power steering

Approach/departure angle

30/19

Wheels & tire

11.00R20

Tire number

6+1

Cargo Dimensions(mm)

8400×2300×600,800

Cubage (m3)

/

RHD or LHD

optional

Overall Dimensions(mm)

12000×2500×3800

Curb weight (Kg)

17200

Engine

Model

YC6A260-33

Horsepower

260

Maximum output Kw

191

Maximum torque N.m

960

Type

6 cylinders, in-line,4-stroke,water-cooled,turbo inter-cooling, diesel engine

Displacement

7.255L

Yuchai brand, Euro 3

Driving passenger

3

Transmission

9 speed forward and one reverse, manual

Front Axle

7.5T x2

Rear Axle

13T x2

Brake System

air brake  ,exhaust brake

Color and LOGO

customized

Electric system

24V

crane

Model

SQS300(XCMG)

Max lifting height

14.5m

Max working radius

12.9m

Max loading

12000kg

Type

Straight arm

Arms number

4

Turning angle

360°

Standard configuration

truck crane equipped between the cabin and van body, mechanical leg,aerial working seat

Optional configuration

Any other famous brand crane, such as Sany Palfinger, it can also be equipped in the rear of the truck, hydraulic legs optional.

Delivery date

Within 30 days after receipt advance

Packing

Nude Pack .The packing of the commodity shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture, shocks and rust according to the special needs of the commodity.
