GVW                                                  Driving Type 4x2

Model

CLW

Cab

Tianjin a row and a half deluxe cab(with sleeping berth),hydraulic mechanical flip, channel type instrument panel, power window,air conditioner, allowable 3 passengers

Engine(Hp)

190

Power(Kw)

140

Wheelbase

4700

Front/Rear Suspension

1430/2470

Steering

Power steering

Approach/departure angle

20/12

Wheels & tire

10.00R20

Tire number

6+1

Cargo Dimensions(mm)

5200×2300×550,600

Cubage (m3)

6.5

RHD or LHD

optional

Overall Dimensions(mm)

8600×2500×3800

Curb weight (Kg)

10000

Engine

Model

B190 33

Horsepower

190

Maximum output Kw

140

Maximum torque N.m

640

Type

6 cylinders, in-line,4-stroke,water-cooled,turbo inter-cooling, diesel engine

Displacement

5.9L

Cummins brand, Euro 3

Driving passenger

3

Transmission

8 speed forward and one reverse, manual

Front Axle

5T

Rear Axle

10T

Brake System

air brake  ,exhaust brake

Color and LOGO

customized

Electric system

24V

crane

Model

SQS200(XCMG)

Max lifting height

13.5m

Max working radius

11.8m

Max loading

8000kg

Type

Straight arm

Arms number

4

Turning angle

360°

Standard configuration

truck crane equipped between the cabin and van body, mechanical leg,aerial working seat

Optional configuration

Any other famous brand crane, such as Sany Palfinger, it can also be equipped in the rear of the truck, hydraulic legs optional.

Delivery date

Within 40 days after receipt advance

Packing

Nude Pack .The packing of the commodity shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture, shocks and rust according to the special needs of the commodity.
