GVW                                                  Driving Type 4x2

Model

CLW

Cab

One row cab, tilted

Engine(Hp)

120

Power(Kw)

88

Wheelbase

3800

Front/Rear Suspension

1180/2070

Steering

Power steering

Approach/departure angle

22/12

Wheels & tire

8.25-16

Tire number

6+1

Cargo Dimensions(mm)

4200×2050×550

Cubage (m3)

3.5

RHD or LHD

optional

Overall Dimensions(mm)

7100×2500×3250

Curb weight (Kg)

5500

Engine

Model

CY4102BZQ

Horsepower

120

Maximum output Kw

88

Maximum torque N.m

328

Type

4 cylinders, in-line,4-stroke,water-cooled,turbo, diesel engine

Displacement

3.856L

Chaoyang brand, Euro 2

Driving passenger

2,3

Transmission

5 speed forward and one reverse, manual

Front Axle

2.5T

Rear Axle

4.5T

Brake System

air brake  ,exhaust brake

Color and LOGO

customized

Electric system

24V

crane

Model

SQS68(XCMG)

Max lifting height

9.5m

Max working radius

7.7m

Max loading

3200kg

Type

Straight arm

Arms number

3

Turning angle

360°

Standard configuration

 truck crane equipped between the cabin and van body, mechanical leg

Optional configuration

Any other famous brand crane, such as Sany Palfinger, it can also be equipped in the rear of the truck, hydraulic legs, aerial working seat is optional.

Delivery date

Within 30 days after receipt advance

Packing

Nude Pack .The packing of the commodity shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture, shocks and rust according to the special needs of the commodity.
