GVW                                                   Driving Type 4x2

Model

CLW

Cab

One row cab, tilted

Engine(Hp)

82

Power(Kw)

60

Wheelbase

3300

Front/Rear Suspension

1032/1663

Steering

Power steering

Approach/departure angle

19/15

Wheels & tire

7.0R16

Tire number

6+1

Cargo Dimensions(mm)

3500×1900×400

Cubage (m3)

3

RHD or LHD

optional

Overall Dimensions(mm)

6000×2000×3000

Curb weight (Kg)

3900

Engine

Model

CY4100Q

Horsepower

82

Maximum output Kw

60

Maximum torque N.m

Type

4 cylinders, in-line,4-stroke,diesel engine

Displacement

3.7L

Chaoyang brand, Euro 2

Driving passenger

2,3

Transmission

5 speed forward and one reverse, manual

Front Axle

2T

Rear Axle

4T

Brake System

air brake  ,exhaust brake

Color and LOGO

customized

Electric system

24V

crane

Model

SQS68(XCMG)

Max lifting height

6.8m

Max working radius

5.5m

Max loading

3200kg

Type

Straight arm

Arms number

2

Turning angle

360°

Standard configuration

 truck crane equipped between the cabin and van body, mechanical leg

Optional configuration

Any other famous brand crane, such as Sany Palfinger, it can also be equipped in the rear of the truck, hydraulic legs, aerial working seat is optional.

Delivery date

Within 20 days after receipt advance

Packing

Nude Pack .The packing of the commodity shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture, shocks and rust according to the special needs of the commodity.
