GVW                                                   Driving Type 6x4

Model

CLW

Cab

SINOTRUK HW76 Lengthen cab, single bunk, new type seat, adjustable steering wheel ,EURO new type heating & ventilating system, German VDO instruments, safety belts, exterior sun visor, stereo radio/cassette recorder, air conditioner

Engine(Hp)

371

Power(Kw)

273

Wheelbase

4600+1350

Front/Rear Suspension

1500/2750

Steering

Power steering

Approach/departure angle

16/14

Wheels & tire

295/80R22.5

Tire number

10+1

Tank capacity(m3)

Bitumen tank 8, Gravel bucket 12

RHD or LHD

optional

Overall Dimensions(mm)

10200×2500×3600

Curb weight (Kg)

17370

Engine

Model

WD615.47

Horsepower

371

Maximum output Kw

273

Maximum torque N.m

1500

Type

6cylinders, in-line,4-stroke,water-cooled,turbo inter-cooling, diesel engine

Displacement

9726ml

Sinotruk brand, Euro 2

Driving passenger

3

Transmission

HW19710,10 forwards,2 reverse

Front Axle

HF7T

Rear Axle

ST16Tx2

Brake System

air brake

exhaust brake

Color and LOGO

customized

Electric system

24V

Tank material

Stainless steel

Standard configuration

Intelligent configuration(Import configuration optional)

Equipment

Bitumen pump

QGB950, 950L/min

Asphalt pump hydraulic drive motor

05-130-BD31

Hydraulic pump

50-20-16

Proportional valve

Taiwan, 160-5-31

Directional and relief valves

Shanxi ,Yuci brand

Radiator

Risheng brand

Control system

German Siemens brand, computer intelligent control

Intelligent bitumen nozzle number

32

Heating method

Heat transfer oil is automatically heated, burner G20 Italian brand

Heat transfer oil pump

China brand or Honda, gasoline engine 5.5KW

Spread

0.25-4.0kg/m2

Spread width

4m

Delivery date

Within 60 days after receipt advance

Packing

Nude Pack .The packing of the commodity shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture, shocks and rust according to the special needs of the commodity.
