GVW                                                   Driving Type 6x4

Model

CLW

Cab

SINOTRUK HW76 Lengthen cab, single bunk, new type seat, adjustable steering wheel ,EURO new type heating & ventilating system, German VDO instruments, safety belts, exterior sun visor, stereo radio/cassette recorder, air conditioner

Engine(Hp)

336

Power(Kw)

247

Wheelbase

4600+1350

Front/Rear Suspension

1500/2650

Steering

Power steering

Approach/departure angle

16/10

Wheels & tire

295/80R22.5

Tire number

10+1

Tank capacity(m3)

14-16

RHD or LHD

optional

Overall Dimensions(mm)

10100×2500×3420

Curb weight (Kg)

11070

Engine

Model

WD615.69

Horsepower

336

Maximum output Kw

247

Maximum torque N.m

1350

Type

6cylinders, in-line,4-stroke,water-cooled,turbo inter-cooling, diesel engine

Displacement

9726ml

Sinotruk brand, Euro 2

Driving passenger

2

Transmission

HW19710,10 forwards,2 reverse

Front Axle

7T

Rear Axle

16Tx2

Brake System

Air brake

Exhaust brake

Color and LOGO

customized

Electric system

24V

Tank material

Stainless steel

Standard configuration

Intelligent configuration(Import configuration optional)

Equipment

Bitumen pump

QGB950, 950L/min

Asphalt pump hydraulic drive motor

05-110-BD31

Hydraulic pump

CBQ550-L

Proportional valve

Taiwan, EFBG-03-160-HF

Directional and relief valves

Shanxi ,Yuci brand

Radiator

Risheng brand

Control system

German Siemens brand, computer intelligent control

Intelligent bitumen nozzle number

36(48)

Heating method

Heat transfer oil is automatically heated, burner G20 Italian brand

Heat transfer oil pump

China brand , gasoline engine 6KW

Spread width

4.5m(6m),0.25-3.5L/m²

Delivery date

Within 60 days after receipt advance

Packing

Nude Pack .The packing of the commodity shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture, shocks and rust according to the special needs of the commodity.
