GVW                                                  Driving Type 4x2

Model

CLW

Cab

Single row cab, allowable 3 passengers.

Engine(Hp)

120

Power(Kw)

88

Wheelbase

3800

Front/Rear Suspension

1180/2280

Steering

Power steering

Approach/departure angle

22/14

Wheels & tire

7.5R16

Tire number

6+1

Tank capacity(m3)

4-5

RHD or LHD

optional

Overall Dimensions(mm)

7400×2300×2800

Curb weight (Kg)

6200

Engine

Model

CY4102BZQ

Horsepower

120

Maximum output Kw

88

Maximum torque N.m

Type

4cylinders, in-line,4-stroke,water-cooled,turbo inter-cooling, diesel engine

Displacement

3856ml

Chaoyang brand, Euro 2

Driving passenger

2,3

Transmission

5 speed forward and one reverse, manual

Front Axle

2.5T

Rear Axle

4.5T

Brake System

air brake

exhaust brake

Color and LOGO

customized

Electric system

24V

Tank material

Stainless steel

Standard configuration

Intelligent configuration(Import configuration optional)

Equipment

Bitumen pump

QGB680, 680L/min

Asphalt pump hydraulic drive motor

05-110-BD31

Hydraulic pump

CBQ550-L

Proportional valve

Taiwan, EFBG-03-160-HF

Directional and relief valves

Shanxi ,Yuci brand

Radiator

Risheng brand

Control system

German Siemens brand, computer intelligent control

Intelligent bitumen nozzle number

34(39)

Heating method

Heat transfer oil is automatically heated, burner G10 Italian brand

Heat transfer oil pump

China brand , gasoline engine 6KW

Spread width

4.5m(6m),025-3L/m²

Delivery date

Within 40 days after receipt advance

Packing

Nude Pack .The packing of the commodity shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture, shocks and rust according to the special needs of the commodity.
