GVW                                                  Driving Type 6x4

Model

CLW

Cab

SINOTRUK cab, air conditioner

Engine(Hp)

371

Power(Kw)

273

Wheelbase

4025+1350

Front/Rear Suspension

1500/3255

Steering

Power steering

Approach/departure angle

16/11

Wheels & tire

12.00R20

Tire number

10+1

Tank capacity(m3)

12

RHD or LHD

optional

Overall Dimensions(mm)

10150×2500×3995

Curb weight (Kg)

14900

Engine

Model

WD615.47

Horsepower

371

Maximum output Kw

273

Maximum torque N.m

1500

Type

6cylinders, in-line,4-stroke,water-cooled,directly injection, diesel engine

Displacement

9726ml

Sinotruk brand, Euro 2

Driving passenger

2

Transmission

Gearbox HW19710,10 speed forward 2 reverse

Front Axle

HF9T

Rear Axle

HC16Tx2

Brake System

air brake

exhaust brake

Color and LOGO

customized

Electric system

24V

Tank material

alloy steel

Standard configuration

Mixer tank, reducer, hydraulic pump, hydraulic motor, radiator, water tank, cleaning hose ,feed port, discharge port, climbing ladder, air pressure water supply device.

Equipment

Tank capacity

12m3

Hydraulic pump

Italy or German or America brand

Hydraulic motor

Italy or German or America brand

Reducer

Italy or German or America brand

Water supply ststem

400L tank , air pressure supply

Radiator

Kaitong brand

Charging speed

≥3M³/ min

Discharging speed

≥3M³/ min

Discharging residual rate

≤0.5%

Delivery date

Within 40 days after receipt advance

Packing

Nude Pack .The packing of the commodity shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture, shocks and rust according to the special needs of the commodity.
