GVW                                                 Driving Type 4x2

Model

CLW

Cab

SINOTRUK H5 cab

Engine(Hp)

220

Power(Kw)

162

Wheelbase

4200

Front/Rear Suspension

1320/2480

Steering

Power steering

Approach/departure angle

22/36

Wheels & tire

11.00-20

Tire number

10+1

Tank capacity(m3)

6

RHD or LHD

optional

Overall Dimensions(mm)

8000×2500×3500

Curb weight (Kg)

9500

Engine

Model

YC6J220-33

Horsepower

220

Maximum output Kw

162

Maximum torque N.m

800

Type

6cylinders, in-line,4-stroke,water-cooled,directly injection, diesel engine

Displacement

6494ml

Yuchai brand, Euro 3

Driving passenger

2

Transmission

6 speed forward 1 reverse ,manual

Front Axle

5T

Rear Axle

10T

Brake System

air brake

exhaust brake

Color and LOGO

customized

Electric system

24V

Tank material

alloy steel

Standard configuration

Mixer tank, reducer, hydraulic pump, hydraulic motor, radiator, water tank, cleaning hose ,feed port, discharge port, climbing ladder, air pressure water supply device.

Equipment

Tank capacity

6m3

Hydraulic pump

Italy or German or America brand

Hydraulic motor

Italy or German or America brand

Reducer

Italy or German or America brand

Water supply ststem

400L tank , air pressure supply

Radiator

Kaitong brand

Charging speed

≥3M³/ min

Discharging speed

≥3M³/ min

Discharging residual rate

≤0.5%

Delivery date

Within 60 days after receipt advance

Packing

Nude Pack .The packing of the commodity shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture, shocks and rust according to the special needs of the commodity.
