GVW                                                  Driving Type 8x4

Model

CLW

Cab

A row and a half deluxe cab(with sleeping berth),hydraulic mechanical flip, channel type instrument panel, air conditioner, allowable 3 passengers

Engine(Hp)

340

Power(Kw)

250

Wheelbase

1850+3400+1350

Front/Rear Suspension

1500/2855

Steering

Power steering

Approach/departure angle

25/16

Wheels & tire

12.00R20

Tire number

12+1

Tank capacity(m3)

16-18

RHD or LHD

optional

Overall Dimensions(mm)

11000×2550×3995

Curb weight (Kg)

14300

Engine

Model

L340 30

Horsepower

340

Maximum output Kw

250

Maximum torque N.m

1350

Type

6cylinders, in-line, turbo,EGR, diesel engine

Displacement

8900ml

Cummins brand, Euro 3

Driving passenger

2,3

Transmission

9 speed forward and one reverse, manual

Front Axle

7T

Rear Axle

13Tx2

Brake System

air brake

exhaust brake

Color and LOGO

customized

Electric system

24V

Tank material

alloy steel

Standard configuration

Mixer tank, reducer, hydraulic pump, hydraulic motor, radiator, water tank, cleaning hose ,feed port, discharge port, climbing ladder, air pressure water supply device.

Equipment

Tank capacity

16-18m3

Hydraulic pump

Italy or German or America brand

Hydraulic motor

Italy or German or America brand

Reducer

Italy or German or America brand

Water supply ststem

400L tank , air pressure supply

Radiator

Kaitong brand

Charging speed

≥3M³/ min

Discharging speed

≥3M³/ min

Discharging residual rate

≤0.5%

Delivery date

Within 30 days after receipt advance

Packing

Nude Pack .The packing of the commodity shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture, shocks and rust according to the special needs of the commodity.
