GVW                                                   Driving Type 6x4

Model

CLW

Cab

A row and a half cab(with sleeping berth),allowable 3 passengers

Engine(Hp)

310

Power(Kw)

228

Wheelbase

3800+1300

Front/Rear Suspension

1250/2605

Steering

Power steering

Approach/departure angle

32/17

Wheels & tire

11.00R20

Tire number

10+1

Tank capacity(m3)

8

RHD or LHD

optional

Overall Dimensions(mm)

9000×2500×3800

Curb weight (Kg)

12900

Engine

Model

YC6L310-33

Horsepower

310

Maximum output Kw

228

Maximum torque N.m

1150

Type

6cylinders, in-line,4-stroke,water-cooled,directly injection, diesel engine

Displacement

8424ml

Yuchai brand, Euro 3

Driving passenger

2,3

Transmission

9 speed forward and one reverse, manual

Front Axle

7T

Rear Axle

13Tx2

Brake System

air brake

exhaust brake

Color and LOGO

customized

Electric system

24V

Tank material

alloy steel

Standard configuration

Mixer tank, reducer, hydraulic pump, hydraulic motor, radiator, water tank, cleaning hose ,feed port, discharge port, climbing ladder, air pressure water supply device.

Equipment

Tank capacity

8m3

Hydraulic pump

Italy or German or America brand

Hydraulic motor

Italy or German or America brand

Reducer

Italy or German or America brand

Water supply ststem

400L tank , air pressure supply

Radiator

Kaitong brand

Charging speed

≥3M³/ min

Discharging speed

≥3M³/ min

Discharging residual rate

≤0.5%

Delivery date

Within 30 days after receipt advance

Packing

Nude Pack .The packing of the commodity shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture, shocks and rust according to the special needs of the commodity.
