GVW                                                  Driving Type 4x2

Model

CLW

Cab

Dongfeng Duolika cab, allowable 3 passengers.

Engine(Hp)

140

Power(Kw)

105

Wheelbase

3800

Front/Rear Suspension

1180/2050

Steering

Power steering

Approach/departure angle

22/21

Wheels & tire

8.25-16

Tire number

6+1

Tank capacity(m3)

4

RHD or LHD

optional

Overall Dimensions(mm)

6850×2500×3400

Curb weight (Kg)

6000

Engine

Model

YC4E140-33

Horsepower

140

Maximum output Kw

105

Maximum torque N.m

500

Type

4cylinders, in-line,4-stroke,water-cooled,directly injection, diesel engine

Displacement

4257ml

Yuchai brand, Euro 3

Driving passenger

2,3

Transmission

5 speed forward and one reverse, manual

Front Axle

2.5T

Rear Axle

5.5T

Brake System

air brake

exhaust brake

Color and LOGO

customized

Electric system

24V

Tank material

alloy steel

Standard configuration

Mixer tank, reducer, hydraulic pump, hydraulic motor, radiator, water tank, cleaning hose ,feed port, discharge port, climbing ladder, air pressure water supply device.

Equipment

Tank capacity

4m3

Hydraulic pump

China brand(Italy or German or America brand optional)

Hydraulic motor

China brand(Italy or German or America brand optional)

Reducer

China brand(Italy or German or America brand optional)

Water supply ststem

400L tank , air pressure supply

Radiator

Kaitong brand

Charging speed

≥3M³/ min

Discharging speed

≥3M³/ min

Discharging residual rate

≤0.5%

Delivery date

Within 30 days after receipt advance

Packing

Nude Pack .The packing of the commodity shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture, shocks and rust according to the special needs of the commodity.
