GVW                                                  Driving Type 4x2

Model

CLW

Cab

One row cab, tilted

Engine(Hp)

116

Power(Kw)

85

Wheelbase

3360

Front/Rear Suspension

1160/1475

Steering

Power steering

Approach/departure angle

20/13

Wheels & tire

7.0R16

Tire number

6+1

Body Dimensions(mm)

4000×1700×1800

Loading capacity(kg)

/

RHD or LHD

optional

Overall Dimensions(mm)

6000×2000×3100

Curb weight (Kg)

2800

Engine

Model

YN4102QBZL

Horsepower

116

Maximum output Kw

85

Maximum torque N.m

290

Type

4 cylinders, in-line,4-stroke,water-cooled,turbo inter-cooling, diesel engine

Displacement

3.76L

Yunnei brand, Euro 2

Driving passenger

2,3

Transmission

6 speed forward and one reverse, manual

Front Axle

2.4T

Rear Axle

4.2T

Brake System

air brake

Color and LOGO

customized

Electric system

24V

Refrigerator unit

-5°or -15°or -18°selective

Standard configuration

van body(inner glass steel, outer glass steel,8cm polyurethane foam insulation),stainless steel locks, stainless steel door frame, with overhead light and anti collision device, domestic refrigeration unit

Delivery date

Within 60 days after receipt advance

Packing

Nude Pack .The packing of the commodity shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture, shocks and rust according to the special needs of the commodity.
